Construction challenges

Today’s construction industry has its own set of unique challenges. Global urbanization, larger infrastructure projects and tough competition have increased pressure to deliver. At the same time, there are a wider range of opportunities than ever for construction companies.

Getting the job done is only part of it. It’s achieving greater productivity, maximising uptime and increasing fuel efficiency that will put you one step ahead of the competition.

Why UD Trucks for construction

UD trucks offer ultimate dependability for construction assignments – whether you’re a driver, an owner, or both. The Quester is strong, reliable and designed for handling high payloads. The Croner is flexible, time-saving and profitable.

Both trucks deliver value-added durability and reliability, more fuel in the tank after every assignment, and major payload possibilities to move your business forward. And with our extensive service offer, we’ve got you covered. Build the future with UD Trucks.

The tough two

Solid, smart and future-designed. Meet UD Trucks’ dependable duo for construction.

Quester

The Quester is UD Trucks main vehicle for construction assignments because of its endurance. A reliable, cost-efficient and versatile workhorse that provides the manoeuvrability and ground clearance to handle the roughest terrain.

Croner

The Croner is a flexible, efficient compliment to the Quester. Suited to more specific construction tasks, it is available in three GVW ranges and saves both time and fuel.

Bodybuilding

The Quester is designed to make superstructure installation easy. Comprehensive bodybuilder instructions and power take offs for specific applications make it ideal
to be adapted for all assignments and road conditions.

solutions-constructions-bodybuiding-quester

Quester Mixer/Concrete

solutions-constructions-bodybuiding-quester-dump

Quester Dump Truck/Tipper

solutions-constructions-bodybuiding-quester-tanker

Quester Concrete pump

solutions-constructions-bodybuiding-quester-tanker

Quester Tanker

solutions-constructions-bodybuiding-croner-mixer

Croner Mixer/Concrete

solutions-constructions-bodybuiding-croner-dump

Croner Dump Truck/Tipper

Break new ground.

Power. Durability. Operational efficiency. Make the most of the 40 tonne Quester, with 24 inch tyres and extra wide, super-strong chassis. In heavy construction, 6×4 and 8×4 rigid configurations provide flexibility to match the truck to the job.



Models suitable for construction

11 models

Croner MKE

Croner MKE

GVW 10.4-11.0 Ton
|
4x2
|
180-210 HP
Quester CKE

Quester CKE

GVW 21.0 Ton
|
4x2
|
250-330 HP
Croner LKE

Croner LKE

GVW 12.0-14.0 Ton
|
4x2
|
180-210 HP
Quester CDE

Quester CDE

GVW 31.0 Ton
|
6x2
|
250-330 HP
Croner PKE

Croner PKE

GVW 15.0-17.0 Ton
|
4x2
|
250-280 HP
Quester CWE

Quester CWE

GVW 34.0 Ton
|
6x4
|
280-420 HP
Quester CGE

Quester CGE

GVW 41.0 Ton
|
8x4
|
370-420 HP
Quester GKE

Quester GKE

GCW56.00 Ton
|
4x2
|
280-420 HP
Quester GDE

Quester GDE

GCW56.00 Ton
|
6x2
|
280-420 HP
Quester GWE

Quester GWE

GCW80.00 Ton
|
6x4
|
280-420 HP
Quester CGE

Quester CGE

GVW 41.0 Ton
|
8x4
|
370-420 HP

Croner MKE Specifications

Axle Configuration
4x2
Engine
GH5E
Weight
GVW 10.4-11.0 Ton
Transmission
6-speed MT; 6-speed AT
Power
180-210 HP
Torque
750; 825; 900
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 5
Application
Cargo

Quester CKE Specifications

Axle Configuration
4x2
Engine
GH8E
Weight
GVW 21.0 Ton
Transmission
6-speed MT; 9-speed MT
Power
250-330 HP
Torque
850; 950; 1050; 1200
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 4
Application
Cargo

Croner LKE Specifications

Axle Configuration
4x2
Engine
GH5E
Weight
GVW 12.0-14.0 Ton
Transmission
6-speed MT; 6-speed AT
Power
180-210 HP
Torque
750; 825; 900
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 4
Application
Cargo
Tipper

Quester CDE Specifications

Axle Configuration
6x2
Engine
GH8E
Weight
GVW 31.0 Ton
Transmission
6-speed MT; 9-speed MT
Power
250-330 HP
Torque
950; 1050; 1200
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Exhaust brake as standard
UD Trucks ECS icon
Euro 3; Euro 4
Application
Cargo

Croner PKE Specifications

Axle Configuration
4x2
Engine
GH8E
Weight
GVW 15.0-17.0 Ton
Transmission
6-speed MT; 9-speed MT; 6-speed AT
Power
250-280 HP
Torque
950; 1050
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 4
Application
Cargo
Compactor
Tipper

Quester CWE Specifications

Axle Configuration
6x4
Engine
GH8E; GH11E
Weight
GVW 34.0 Ton
Transmission
9-speed MT; 12-speed MT
Power
280-420 HP
Torque
1050; 1200; 1734; 1800; 2000
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 4
Application
Mixer

Quester CGE Specifications

Axle Configuration
8x4
Engine
GH11E
Weight
GVW 41.0 Ton
Transmission
9-speed MT; 12-speed MT
Power
370-420 HP
Torque
1050; 1200; 1734; 1800; 2000
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 4
Application
Tipper

Quester GKE Specifications

Axle Configuration
4x2
Engine
GH8E; GH11E
Weight
GCW56.00 Ton
Transmission
9-speed MT; 12-speed MT
Power
280-420 HP
Torque
1050; 1200; 1734; 1800; 2000
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 4
Application
Tractor

Quester GDE Specifications

Axle Configuration
6x2
Engine
GH8E; GH11E
Weight
GCW56.00 Ton
Transmission
9-speed MT; 12-speed MT
Power
280-420 HP
Torque
1050; 1200; 1734; 1800; 2000
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 4
Application
Tractor

Quester GWE Specifications

Axle Configuration
6x4
Engine
GH8E; GH11E
Weight
GCW80.00 Ton
Transmission
9-speed MT; 12-speed MT
Power
280-420 HP
Torque
1050; 1200; 1734; 1800; 2000
Braking System
Full air brake system; Automatic slack adjuster; ABS optional; Spring-based parking brakes; Exhaust brake system
UD Trucks ECS icon
Euro 3; Euro 4
Application
Tractor

Quester CGE Specifications

Axle Configuration
8x4
Engine
GH11E
Weight
GVW 41.0 Ton
Transmission
9-speed MT
Power
370-420 HP
Torque
1734
Braking System
ABS optional
UD Trucks ECS icon
Euro 3

A durable partnership.

Construction projects demand the best support network possible. UD Extra Mile Support keeps your trucks working for you. Every hour, day or night.

1

UD Telematics

A high-tech wireless communications system designed to help you manage your fleet effectively, keeping wheels turning while reducing operational costs.

1

UD Trust

Two levels of service care are available for construction: UD Trust Standard and UD Trust Extra. Both offer full transparency, no surprise costs and less administration.

1

UD Road Support

A fast and efficient UD Road Support team provide repair services at your convenience to get you back on the road as fast as possible. Anytime.

Expert Story

614x346-toshi-new

“ We constantly develop to go the extra mile on profitability.”

Toshi Odawara, VP – UD Trucks Heavy Duty Product Line Management, talks about what makes the Quester the right choice for construction.

Can you tell us about your role?

“I am responsible for creating a product plan for the Quester and bringing it to markets across the globe. I have been working at UD Trucks for 20 years.

Overall this role is about capturing our customers’ essential needs. It is important to make sure that the Quester can create profitable business. It’s key for me to constantly visit markets, customers and our dealer network, to get an understanding of real situations and challenges in customers’ lives. Their feedback drives the development of the Quester, the truck they need today.”

What makes the Quester essential for the construction market?

Construction assignments are diverse. The truck has to handle multi tasks and must be simple and robust. It operates in different conditions such as hilly and rough muddy roads to smooth highways.  Sometimes at slow speeds for a long time or high speeds to minimise trip time. At the same time they need to carry high loads to increase productivity. Quester specifications can operate in these various conditions. The truck has been tested in various markets for long distances, so that we make sure customers will be satisfied with the toughness and robustness. We have also ensured Quester has high ground clearance that can cope in construction and mining.For this, we have prepared a three-piece steel bumper, high mounted brake chamber and hub reduction as an option.

With Quester you get a truck designed to go the extra mile that boasts a real heavyduty cab, chassis and engine, with modern and smart design.”

What are the most important considerations in today’s markets?

“To focus on what customers’ essential needs are, and to provide the kind of truck that can fulfil those needs. Simple and robust, easy to maintain, keeps working, and low downtime. We don’t want customers to suffer with maintenance or downtime due to complex technology or systems, but to keep their asset up and running. We want customers to profit and be successful in their business by investing in our products. For drivers it’s all about ease of driving and a comfortable spacious cabin. The Quester excels on the essentials such as fuel efficiency and uptime. We have developed a wide range of offers and adaptations that ensure our customers get exactly the right truck for the right job. Today we see a solid growth in demand for the Quester. The feedback from our customers makes me really proud to be part of this journey.”

Customer Success Story

Firas Sader Al Deen, Transportation Manager.

"We hope that this partnership keeps growing with our company and projects."
